Conley Terminal
Controlling Depth Matrix
Pier 1 Controlling Depth Matrix
| Berth | Wharf Length (Feet) | Berth Length (Feet) | Controlling Depth (Feet) | Date of Sounding |
|---|---|---|---|---|
| North Face | 607 | 15.9 | 6/11/2015 | |
| South Face | 607 | 25.2 | 6/11/2015 | |
| West Face | 390 | 17.1 | 6/11/2015 |
Fish Pier Controlling Depth Matrix
| Berth | Wharf Length (Feet) | Berth Length (Feet) | Authorized Depth (Feet) | Controlling Depth (Feet) | Date of Sounding |
|---|---|---|---|---|---|
| East - 1 | 1115 | 157.8 | 24.0 | 12.1 | 6/10/2015 |
| East - 2 | 1115 | 117.9 | 24.0 | 16.0 | 6/10/2015 |
| East - 3 | 1115 | 117.9 | 24.0 | 4.8 | 6/10/2015 |
| East - 4 | 1115 | 119.0 | 24.0 | 6.2 | 6/10/2015 |
| East - 5 | 1115 | 119.0 | 24.0 | 11.1 | 6/10/2015 |
| East - 6 | 1115 | 95.8 | 24.0 | 12.5 | 6/10/2015 |
| East - 7 | 1115 | 95.7 | 24.0 | 14.0 | 6/10/2015 |
| East - 8 | 1115 | 95.1 | 24.0 | 13.6 | 6/10/2015 |
| East - 9 | 1115 | 95.1 | 24.0 | 15.2 | 6/10/2015 |
| East - 10 | 1115 | 101.4 | 24.0 | 14.8 | 6/10/2015 |
| West - 1 | 1115 | 175.2 | 24.0 | 17.2 | 6/16/2020 |
| West - 2 | 1115 | 89.2 | 24.0 | 19.8 | 6/16/2020 |
| West - 3 | 1115 | 89.2 | 24.0 | 16.8 | 6/16/2020 |
| West - 4 | 1115 | 92.3 | 24.0 | 18.3 | 6/16/2020 |
| West - 5 | 1115 | 92.2 | 24.0 | 18.5 | 6/16/2020 |
| West - 6 | 1115 | 93.2 | 24.0 | 17.4 | 6/16/2020 |
| West - 7 | 1115 | 93.1 | 24.0 | 18.0 | 6/16/2020 |
| West - 8 | 1115 | 83.7 | 24.0 | 17.0 | 6/16/2020 |
| West - 9 | 1115 | 83.7 | 24.0 | 17.2 | 6/16/2020 |
| West - 10 | 1115 | 70.0 | 24.0 | 17.5 | 6/16/2020 |
| West - 11 | 1115 | 70.1 | 24.0 | 19.7 | 6/16/2020 |
| West - 12 | 1115 | 102.1 | 24.0 | 19.0 | 6/16/2020 |
| North - 1 | 380 | 380.0 | 24.0 | 14.1 | 6/16/2020 |
